| Borehole diameter (mm) |
50 |
| The spindle end face to the workbench distance (mm) |
260-1150 |
| Spindle center to post busbar distance (mm) |
360-1600 |
| Main shaft trip (mm) |
220 |
| The spindle taper hole (mo) |
5 |
| The spindle speed range (R.P.M) |
78、135、240、350、590、1100 |
| The spindle speed series |
6 |
| The spindle feed range (R.P.M) |
0.10-0.56 |
| Spindle feed series |
6 |
| For the turning Angle of rocker arm (°) |
360 |
| The main motor power (kw) |
4 |
| Lifting motor power (kw) |
1.5 |
| Machine weight (kg) |
2800 |
| Overall dimensions (mm) |
2170×950×2450 |
